• Angle Gear Reseal Kit parts diagram for the S60/V70/S80

Genuine Volvo Angle Gear Reseal Kit, S60/V70/S80

$208.99 $189.99
(You save $19.00)
Brand:
SKU:
VP-012864
Availability:
Normally ships next business day
Current Stock:
1
QUANTITY:

Product Description

ViVA Performance has put together a complete kit with all the necessary seals and gaskets to reseal and repair leaking angle gears. This kit is made up entirely of Genuine Volvo parts and will work with Volvo's most updated AWD Angle Gear Part Numbers: 36000340 and 36000343.

Note: The kit includes seals found between the angle gear and rear driveline/driveshaft and right axle. Any seals found between the collar sleeve and angle gear are included in the various Collar Sleeve Kits we offer.

Kit Contents:

  1. Drive Line Seal, OD 45mm (for angle gear PNs 8603809, 36000272 or 36000340) and Drive Line Seal, OD 39 mm (for angle gear PN 8602919)
  2. Drive Shaft Seal, OD 38mm (for M66 AWD 6-speed manual gearboxes, and AW 50/51 5-speed automatic gearboxes) and Drive Shaft Seal, OD 40mm (for TF-80SC AWD 6-speed automatic gearboxes)
  3. O-Ring
  4. Seal Ring, OD 65mm
  5. Bleeder Nipple (updated design introduced in 2008)
  6. Bleeder Filter (updated design introduced in 2008)
  7. Wurth Silicone Super RTV 6.75 fl oz

Vehicle Fitment

  • S60 AWD 2003-2009
  • V70 AWD 2003-2007
  • S60R/V70R 2004-2007
  • S80 AWD 2004-2006
  • XC70 AWD 2003 - 2007
  • XC90 2.5T T6 AWD 2003-2006
