Snabb Performance Intercooler, Volvo 850, S/C/V70

$499.99
$429.95
(You save $70.04)
  • SKU: AL-0315
  • Availability: Normally ships in 1-2 business days
  • Share This

    DESCRIPTION

    Improve the performance of your Turbo Volvo by installing a high quality, all aluminum, drop-in Performance Intercooler by Snabb Performance Parts. AL-0315 fits Volvo 850, S/C/V70 models.

    The Snabb drop-in Intercooler has been completely redesigned from the ground up for the best possible construction, fitment and performance, all at the best price. We've made a beautifully crafted drop in replacement that is capable of handling even big 500 hp builds and yet still be cost effective and affordable.

    This performance intercooler has been thoroughly Dyno AND Street tested using our own custom logging setup. Pressure and temperature are tested in real time at the intercooler inlet and the intercooler outlet. We found that even on a Dyno with insufficient airflow, our Performance Intercooler could still remove more than 2 times as much heat as our competitor's tube and fin Intercooler. On the street, the Snabb intercooler rejects nearly 4 times more heat than the Competitors.

    During the road tests, the Snabb Intercooler showed a maximum intercooler outlet temp of 63.5 degrees F at WOT in third gear (at an ambient temp of 50 degrees) with 89% intercooler efficiency. This means there will be less detonation and more power under load. Making sure that your inlet air is cool is one of the most important parts of the equation for a turbocharged car. In comparison a popular competitor's intercooler showed a maximum outlet temp of 117 degrees F at WOT in third gear (ambient temp of 56 degrees) with a calculated intercooler efficiency of 49%. The temperature at the intercooler outlet was 61 degrees above ambient under the same conditions or almost 50 degree higher than the Snabb Performance Intercooler.


    Intercooler Kit Features:

    • 2" Thick Precision Snabb High Density All Aluminum Core
    • 32 tubes for maximum heat dispersion
    • Pressure drop of 1 psi at 15lbs of boost
    • Easy install with precise mounting holes and welded spacers to make alignment with radiator and condenser a breeze
    • Pressure tested to 145 psi for 30 minutes
    • Effective for up to 500 HP applications
    • Clean silver painted surface
    • Included mounting hardware

    Installation Instructions: pdf.gif

    **Note: This intercooler is compatible with the OEM intercooler piping and as well as the 93-98 and 99+ Reverse Intercooler Piping (RIP) Kits. If you need to install this on a vehicle equipped with another intercooler piping set, please Contact Us to check for fitment.

    TECHNICAL DETAILS

  • Unit of Measure: Sold as a Kit
